Product Summary
The ADF7021bCPZ is a high performance, low power, highly integrated 2FSK/3FSK/4FSK transceiver. It is designed to operate in the narrow-band, license-free ISM bands, and in the licensed bands with frequency ranges of 80 MHz to 650 MHz and 862 MHz to 950 MHz. The part has both Gaussian and raised cosine transmit data filtering options to improve spectral efficiency for narrow-band applications. It is suitable for circuit applications targeted at European ETSI EN 300 220, the Japanese ARIB STD-T67, the Chinese short range device regulations, and the North American FCC Part 15, Part 90, and Part 95 regulatory standards.
Parametrics
Absolute maximum ratings:(1)VDD to GND: -0.3 V to +5 V;(2)Analog I/O Voltage to GND: -0.3 V to VDDx+0.3 V;(3)Digital I/O Voltage to GND: -0.3 V to VDDx + 0.3 V;(4)Operating Temperature Range Industrial (B Version): -40℃ to +85℃;(5)Storage Temperature Range: -65℃ to +125℃;(6)Maximum Junction Temperature: 150℃; (7)MLF θJA Thermal Impedance: 26℃/W; (8)Reflow Soldering: Peak Temperature: 260℃; Time at Peak Temperature: 40 sec.
Features
Features: (1)Low power, narrow-band transceiver; (2)Frequency bands using dual VCO: 80 MHz to 650 MHz; 862 MHz to 950 MHz; (3)Modulation schemes: 2FSK, 3FSK, 4FSK, MSK; (4)Spectral shaping Gaussian and raised cosine filtering; (5)Data rates supported 0.05 kbps to 32.8 kbps; (6)2.3 V to 3.6 V power supply; (7)Programmable output power: 16 dBm to +13 dBm in 63 steps; (8)Automatic PA ramp control; (9)Receiver sensitivity: 130 dBm at 100 bps, 2FSK; 122 dBm at 1 kbps, 2FSK; 113 dBm at 25 kbps, raised cosine 2FSK; (10)Patent pending, on-chip image rejection calibration; (11)On-chip VCO and fractional-N PLL; (12)On-chip, 7-bit ADC and temperature sensor; (13)Fully automatic frequency control loop (AFC); (14)Digital received signal strength indication (RSSI); (15)Integrated Tx/Rx switch; (16)0.1 μA leakage current in power-down mode.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADF7021BCPZ |
|
IC TXRX ISM HI PERFORM 48-LFCSP |
Data Sheet |
|
|
||||||||||||||||||
|
ADF7021BCPZ-RL |
|
IC TXRX ISM HI PERFORM 48-LFCSP |
Data Sheet |
|
|
||||||||||||||||||
|
ADF7021BCPZ-RL7 |
|
IC TXRX ISM HI PERFORM 48-LFCSP |
Data Sheet |
|
|
||||||||||||||||||
