Product Summary

The MCL25 is a general purpose midget class MCL. The applications of it are Control circuits, electronic equipment protection, street lighting holders, and HID lighting.

Parametrics

MCL25 general specifications: (1)Voltage Rating: MCL - 600 VAC; (2)Ampere Rating: 0.5 - 50 Amps; (3)Interrupting Rating: 100,000 RMS Amps.

Features

MCL25 features: (1)Provide supplemental protection to end-use equipment; (2)Compact dimensions; (3)High interrupting rating; (4)Fast-acting design responds quickly to both overloads and short-circuit current.

Diagrams

MCL25 package dimensions
