Product Summary

The LM710H883 is a high-speed voltage comparators intended for use as an accurate, low-level digital level sensor or as a replacement for operational amplifiers in comparator applications where speed is of prime importance. The circuit has a differential input and a single-ended output, with saturated output levels compatible with practically all types of integrated logic.

Parametrics

LM710H883 absolute maximum ratings: (1)Positive Supply Voltage: +14V; (2)Negative Supply Voltage: −7V; (3)Peak Output Current: 10 mA; (4)Output Short Circuit Duration: 10 seconds; (5)Differential Input Voltage: ±5V; (6)Input Voltage: ±7V; (7)Power Dissipation TO-99 (Note 1): 700 mW; (8)Plastic Dual-In-Line Package (Note 2): 950 mW; (9)Operating Temperature Range: −55°C to +125°C; (10)Storage Temperature Range: −65°C to +150°C; (11)Lead Temperature (Soldering, 10 sec): 260°C.

Diagrams

LM710H883 pin connection
