Product Summary

The LT1509ISW is a complete solution for universal off-line switching power supplies utilizing active power factor correction. The PFC section is identical to the LT1248 PFC controller except the EN/SYNC pin is removed because PFC and PWM are synchronized internally. Application is universal power factor corrected power supplies and preregulators.

Parametrics

LT1509ISW absolute maximum ratings: (1)Supply voltage: 27V; (2)GTDR current continuous: 0.5A; (3)GTDR output energy: 5mJ; (4)IAC, RSET, PKLIM Input Current : 20mA; (5)VSENSE, OVP input voltage: VMAX; (6)RAMP, VC input voltage: 8V; (7)ISENSE, MOUT input current: ±5mA; (8)Operating junction temperature range commercial: 0°C to 100°C; (9)Operating junction temperature range industrial: –40°C to 125°C; (10)Thermal Resistance (Junction-to-Ambient)N Package: 100°C/W; (11)SW package: 120°C/W。
