Product Summary

The MC33179 is a family of high quality monolithic op-amps employing Bipolar technology with innovative high performance concepts for quality audio and data signal processing applications. This MC33179 family incorporates the use of high frequency PNP input transistors to produce amplifiers exhibiting low input offset voltage, noise and distortion. MC33179 is widely used in audio and data signal processing.

Parametrics

MC33179 maximum ratings: (1)Supply Voltage (VCC to VEE): VS= +36 V; (2)Input Differential Voltage Range VIDR: V; (3)Input Voltage Range VIR: V; (4)Output Short Circuit Duration: Indefinite sec; (5)Maximum Junction Temperature: +150 ℃; (6)Storage Temperature Range: –60 to +150 ℃; (7)Maximum Power Dissipation PD: mW.

Features

MC33179 features: (1)600Ω Output Drive Capabilit; (2)Large Output Voltage Swing; (3)Low Offset Voltage: 0.15 mV (Mean); (4)Low Total Harmonic Distortion: 0.0024%; (5)High Gain Bandwidth: 5.0 MHz; (6)High Slew Rate: 2.0 V/μs; (7)Dual Supply Operation: +/-2.0 V to +/-18 V; (8)ESD Clamps on the Inputs Increase Ruggedness without Affecting Device Performance; (9)Pb-Free Package is Available.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MC33179
MC33179

Other


Data Sheet

Negotiable
MC33179D
MC33179D

ON Semiconductor

Operational Amplifiers - Op Amps 2-18V Quad Low Power

Data Sheet

Negotiable
MC33179DG
MC33179DG

ON Semiconductor

Operational Amplifiers - Op Amps 2-18V Quad Low Power Industrial Temp

Data Sheet

0-1: $0.61
1-25: $0.54
25-100: $0.39
100-500: $0.33
MC33179DR2
MC33179DR2

ON Semiconductor

Operational Amplifiers - Op Amps 2-18V Quad Low Power

Data Sheet

Negotiable
MC33179DR2G
MC33179DR2G

ON Semiconductor

Operational Amplifiers - Op Amps 2-18V Quad Low Power Industrial Temp

Data Sheet

0-1: $0.70
1-25: $0.61
25-100: $0.48
100-500: $0.45
MC33179DTBR2G
MC33179DTBR2G

ON Semiconductor

Operational Amplifiers - Op Amps ANA LO-PWR/LO-NSE QUAD OA

Data Sheet

0-1: $1.18
1-25: $0.94
25-100: $0.75
100-500: $0.60
MC33179P
MC33179P

ON Semiconductor

Operational Amplifiers - Op Amps 2-18V Quad Low Power

Data Sheet

Negotiable
MC33179PG
MC33179PG

ON Semiconductor

Operational Amplifiers - Op Amps 2-18V Quad Low Power Industrial Temp

Data Sheet

0-1: $0.73
1-25: $0.65
25-100: $0.47
100-500: $0.41
