MAX2323

MAX2323, LNA/Mixer ICs, 4.3 V, 3 mA, 6.4 W, 0.1 μA, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	0.50 / Piece

PartNumber:: MAX2323

Brand:: Dallas Semiconductor - Maxim | Pack: BGA | D/C: 10+

Availability:: Supply Ability: 5000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Laneya's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-27

From Other Seller

Part Number:MAX2323
US $0.50 - 0.50
Quantity:

piece

Product Summary

The MAX2323 is an adjustable, high-linearity, sige dual-band LNA/Mixer ICs. The MAX2323 high-performance silicon germanium (SiGe) receiver front-end ICs set a new industry standard for low noise and high linearity at a low supply current. This family integrates a variety of unique features such as an LO frequency doubler and divider, dual low-noise amplifier (LNA) gain settings, and a low-current paging mode that extends the handset standby time. Applications are (1)CDMA/TDMA/PDC/WCDMA/GSM Cellular Phones; (2)Single/Dual/Triple-Mode Phones; (3)Wireless Local Loop (WLL).

Parametrics

MAX2323 absolute maximum ratings: (1)VCC to GND: -0.3V to +4.3V; (2)Digital Input Voltage to GND: -0.3V to (VCC + 0.3V); (3)RF Input Signals: 1.0V peak; (4)Continuous Power Dissipation (TA = +70°C)20-Pin TSSOP-EP (derate 80mW/°C above +70°C): 6.4W; (5)Operating Temperature Range: -40°C to +85°C; (6)Junction Temperature: +150°C; (7)Storage Temperature Range: -65°C to +150°C; (8)Lead Temperature (soldering, 10s): +300°C.

Features

MAX2323 features: (1)Ultra-High Linearity at Ultra-Low Current and Noise; (2)+2.7V to +3.6V Operation; (3)Pin-Selectable Low-Gain Mode Reduces Gain by 17dB and Current by 3mA; (4)Pin-Selectable Paging Mode Reduces Current Draw by 6mA when Transmitter Is Not in Use; (5)LO Output Buffers; (6)0.1μA Shutdown Current; (7)20-Pin TSSOP-EP Package.
