Product Summary
The MSS1278-563MLD is a kind of SMT power inductor.
Parametrics
MSS1278-563MLD absolute maximum ratings: (1)Ambient temperature: –40℃ to +85 with Irms current, +85℃ to +125℃ with derated current; (2)Storage temperature Component: –40℃ to +125℃.; (3)Packaging: –40℃ to +80℃; (4)Resistance to soldering heat Max three 40 second reflows at; (5)+260℃, parts cooled to room temperature between cycles; (6)Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30℃ /85% relative humidity).
Features
MSS1278-563MLD features: (1)12.3 × 12.3 mm footprint; 8 mm high shielded inductors; (2) Low DCR and excellent current handling.
Diagrams
 |
