Product Summary
The RTL8306G is a highly integrated layer 2 single chip switch controller which incorporates 5 MACs (Media Access Controller), 5 physical layer transceivers, 1-Mbit SRAM and 1K-entry look-up table into one single chip. The RTL8306G contains 5 ports, and each one provides support for a 10Base-T (10Mbps) or 100Base-TX (100Mbps) network connection. The RTL8306G is designed for a stand-alone switch system through hardware strapping upon reset to achieve unmanaged operation and can be easily integrated with xDSL/Cable modem router.
Parametrics
RTL8306G absolute maximum ratings: (1)Storage Temperature: -45 to +125 ℃; (2)Vcc Supply Referenced to GND: -0.5 to +4.0 V; (3)Digital Input Voltage: -0.5 to Vcc V; (4)DC Output Voltage: -0.5 to Vcc V.
Features
RTL8306G features: (1)5-port integrated switch with physical layer and transceiver for 10Base-T and 100Base-TX with 5-port 10/100M UTP or 4-port 10/100M UTP + 1-port MII/SNI; (2)PHY mode MII/SNI interface for router application; (3)MAC mode MII interface for HomeLAN/100Base-FX application; (4)1Mbit internal RAM for packet buffer; (5)Internal 1K look-up table entries; (6)25MHz crystal or OSC input; (7)Non-blocking wire-speed reception and transmission; (8)LEDs blinking upon reset for LED diagnostics; (9)Unmanaged operation by strapping upon reset; (10)Power saving with cable detection; (11)Low power consumption at 3.3V operating voltage; (12)Supports broadcast storm filtering function; (13)128-pin PQFP package.
Diagrams
 |
