Product Summary

The VI-26N-CU, with over 8 million shipped, is Vicors first generation of zero-current-switching component-level DC-DC converter. Operating at frequencies up to 2 MHz, VI-200 Family Converters offer exceptional power density, efficiency, noise performance, reliability and ease of use. Power Boosters provide a simple, cost effective, off-the-shelf solution for higher power output requirements. One or more boosters may be used to create synchronous arrays capable of supplying several kilowatts of output power. The flexibility of Vicors power components is also available in half-size, half-power VI-J00 MiniMods.

Parametrics

Absolute maximum ratings: (1)Inrush charge, Coulombs: 120x10-6 to 200x10-6; (2)Input reflected ripple current – pp, IIN: 10%; (3)Setpoint accuracy, VNOM: 0.5% to 1%; (4)Load/line regulation, VNOM: 0.05% to 0.2%; (5)Load/line regulation, VNOM: 0.2% to 0.5%; (6)Output temperature drift, 0.01 to 0.02%/°C; (7)Long term drift: 0.02 %/1Khours; (8)Trim range: 50% to 110%; (9)Total remote sense compensation: 0.5Volts; (10)OVP set point, VNOM: 115% to 135%; (11)Current limit, INOM: 105% to 125%; (12)Short circuit current, INOM: 20% to 130%.

Features

Features: (1)Up to 50W/Cubic Inch; (2)UL, CSA, TUV, VDE, BABT,AUSTEL; (3)Up to 90% Efficiency; (4)Size: 4.6" x 2.4" x 0.5"(116,8 x 61,0 x 12,7); (5)Remote Sense and Current Limit; (6)OVP, Thermal Shutdown; (7)Logic Disable; (8)Wide Range Output Adjust; (9)Compatible Power Booster Modules; (10)ZCS Power Architecture; (11)Low Noise FM Control; (12)CE Marked.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
VI-26N-CU-S
VI-26N-CU-S


CONVERTER MOD DC/DC 18.5V 200W

Data Sheet

0-1: $162.60
VI-26N-CU-F4
VI-26N-CU-F4


CONVERTER MOD DC/DC 18.5V 200W

Data Sheet

0-1: $173.13
VI-26N-CU-F3
VI-26N-CU-F3


CONVERTER MOD DC/DC 18.5V 200W

Data Sheet

0-1: $173.13
VI-26N-CU-F2
VI-26N-CU-F2


CONVERTER MOD DC/DC 18.5V 200W

Data Sheet

0-1: $165.60
VI-26N-CU-F1
VI-26N-CU-F1


CONVERTER MOD DC/DC 18.5V 200W

Data Sheet

0-1: $173.13
VI-26N-CU-B1
VI-26N-CU-B1


CONVERTER MOD DC/DC 18.5V 200W

Data Sheet

0-1: $183.57
VI-26N-CU
VI-26N-CU


CONVERTER MOD DC/DC 18.5V 200W

Data Sheet

0-1: $163.56
