Product Summary

The mc145152p is programmed by 14 parallel–input data lines for the N counter and three input lines for the R counter. The mc145152p device features consist of a reference oscillator, selectable–reference divider, digital–phase detector, and 14–bit programmable divide–by–N counter.

Parametrics

mc145152p maximum ratings: (1)Operating Temperature Range: -40 to 85℃; (2)Low Power Consumption Through Use of CMOS Technology; (3)3.0 to 9.0 V Supply Range; (4)On-or Off-chip Reference Oscillator Operation; (5)Lock Detect Signal; (6)N Counter Output Available; (7)Single Modulus/Parallel Programming.

Features

mc145152p features: (1)8 User-selectable + R Values: 8, 128, 256, 512, 1024, 2048, 2410, 8192; (2)+N Range = 3 to 16383; (3)Linearized Digital Phase Detector Enhances Transfer Function Linearity; (4)Two Error Signal Options: Single-Ended (Three-state) or Double-Ended; (5)Chip Complexity: 8000 FETs or 2000 Equivalent Gates.

Diagrams
