Product Summary

The BAS16 is a high-speed switching diode. It is encapsulated in small Surface-Mounted Device (SMD) plastic packages. It is suitable for high-speed switching and general-purpose switching.

Parametrics

BAS16 absolute maximum ratings: (1)Tj junction temperature: - 150 ℃ max; (2)Tamb ambient temperature: -65 +150 ℃; (3)Tstg storage temperature: -65 +150 ℃.

Features

BAS16 features: (1)High switching speed: trr≤4ns; (2)Low capacitance; (3)Low leakage current; (4)Reverse voltage: VR≤100 V; (5)Repetitive peak reverse voltage: VRRM≤100 V; (6)Small SMD plastic packages.

Diagrams

BAS16 Graphic symbol

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BAS16
BAS16
Taiwan Semiconductor
Diodes (General Purpose, Power, Switching) Switching diode 225 mW
Data Sheet
0-3000: $0.01
3000-6000: $0.01
BAS16,215
BAS16,215
NXP Semiconductors
Diodes (General Purpose, Power, Switching) SW 75V 215MA HS
Data Sheet
0-1: $0.03
1-25: $0.01
25-100: $0.01
100-250: $0.01
BAS16,235
BAS16,235
NXP Semiconductors
Diodes (General Purpose, Power, Switching) DIODE SW TAPE-11
Data Sheet
0-1: $0.03
1-25: $0.01
25-100: $0.01
100-250: $0.01
BAS16_Q
BAS16_Q
Fairchild Semiconductor
Rectifiers 85V 200mA
Data Sheet
Negotiable
BAS16_S00Z
BAS16_S00Z
Fairchild Semiconductor
Rectifiers High Conductance Ultra Fast
Data Sheet
Negotiable
BAS16-02L
BAS16-02L
Other

Data Sheet
Negotiable
BAS16-02V
BAS16-02V
Other

Data Sheet
Negotiable
BAS1602VE6327XT
BAS1602VE6327XT
Infineon Technologies
Diodes (General Purpose, Power, Switching) Silicon Switching Diode
Data Sheet
Negotiable
