Product Summary

The ITS4141N is a Smart High-Side Power Switch. The appications of it are All types of resistive, inductive and capacitive loads, uC compatible power switch for 12 V and 24 V DC industrial applications, Replaces electromechanical relays and discrete circuits.

Parametrics

ITS4141N absolute maximum ratings: (1)Supply voltage:-0.3 to 48 V; (2)Continuous input voltage:-10Vbb; (3)Load current:self limited; (4)Current through input pin (DC):±5 mA; (5)Reverse current through GND-pin:-0.5 A; (6)Junction temperature:internal limited; (7)Operating temperature:-30 to +85 °C; (8)Storage temperature:-40 to +105 °C; (9)Power dissipation:1.4 W.

Features

ITS4141N features: (1)Short circuit protection; (2)Current limitation; (3)Overload protection; (4)Overvoltage protection(including load dump); (5)Undervoltage shutdown with autorestart and hysteresis; (6)Switching inductive loads; (7)Clamp of negative voltage at output with inductive loads; (8)CMOS compatible input; (9)Thermal shutdown with restart; (10)ESD - Protection; (11)Loss of GND and loss of Vbb protection; (12)Very low standby current; (13)Reverse battery protection with external resistor; (14)Improved electromagnetic compatibility (EMC).

Diagrams

ITS4141N block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
ITS4141N
ITS4141N

Infineon Technologies

Power Switch ICs - Power Distribution SMART HI SIDE PWR SWITCH INDUSTRY APP

Data Sheet

0-2970: $0.43
2970-4000: $0.43
4000-8000: $0.42
8000-12000: $0.40
