Product Summary
The BTS436L2 is a smart high side power switch. It is widely used in uc compatible high-side power switch with diagnostic feedback for 5V, 12V and 24V grounded loads, all types of resistive, inductive and capacitve loads, most suitable for loads with high inrush currents, so as lamps, replaces electromechanical relays, fuses and discrete circuits.
Parametrics
BTS436L2 absolute maximum ratings: (1)Supply voltage,Vbb: 43V; (2)Load dump protection, VLoad dump: 60V; (3)Load current, IL: self-limited A; (4)Operating temperature range, Tj: -40 to +150℃; (5)Storage temperature range, Tstg: -55 to+150℃; (6)Power dissipation (DC), TC ≤ 25℃, Ptot: 75W.
Features
BTS436L2 features: (1)N channel vertical power MOSFET with charge pump; (2)ground referenced CMOS compatible input and; (3)diagnostic feedback; (4)monolithically integrated in Smart SIPMOS technology; (5)Providing embedded protective functions.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BTS436L2 |
|
IC HIGH SIDE PWR SWITCH TO220-5 |
Data Sheet |
Negotiable |
|
||||||||||||||
 |
BTS436L2G |
Infineon Technologies |
Power Switch ICs - POE / LAN PROFET SMART HI SIDE PWR SW |
Data Sheet |
|
|
||||||||||||||
|
BTS436L2S |
|
IC HIGH SIDE PWR SWITCH TO220-5 |
Data Sheet |
Negotiable |
|
||||||||||||||
