Product Summary
The TL431ACZ is a programmable shunt voltage reference with guaranteed temperature stability over the entire temperature range of operation. The output voltage of TL431ACZ may be set to any value between 2.5V and 36V with two external resistors. The TL431ACZ operates with a wide current range from 1 to 100mA with a typical dynamic impedance of 0.22W.
Parametrics
TL431ACZ absolute maximum ratings: (1)Cathode to Anode Voltage, VKA: 37V; (2)Continuous Cathode Current Range, Ik: -100 to +150mA; (3)Reference Input Current Range, Iref: -0.05 to +10mA; (4)Power Dissipation, pd: 960mW; (5)Storage Temperature Range, Tstg: -65 to +150℃.
Features
TL431ACZ features: (1)adjustable output voltage: 2.5 to 36V; (2)sink current capability: 1 to 100mA; (3)typical output impedance: 0.22W; (4)1% and 2% voltage precision.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TL431ACZ |
STMicroelectronics |
Voltage & Current References 2.5-36V Prog Adjust |
Data Sheet |
|
|
||||||||||||
|
TL431ACZ-AP |
STMicroelectronics |
Voltage & Current References 2.5-36V Prog Adjust |
Data Sheet |
|
|
||||||||||||
|
TL431ACZT |
STMicroelectronics |
Voltage & Current References 2.5-36V Prog Adjust |
Data Sheet |
|
|
||||||||||||
|
TL431ACZX |
Fairchild Semiconductor |
Voltage & Current References Programmable Shunt 0.01 |
Data Sheet |
Negotiable |
|
||||||||||||
