Product Summary
The SM6T36CA is a Transil diode. It provides high overvoltage protection by clamping action. Its instantaneous response to transient overvoltages makes SM6T36CA particularly suited to protect voltage sensitive devices such as MOS Technology and low voltage supplied IC.
Parametrics
SM6T36CA absolute maximum ratings: (1)PPP Peak pulse power dissipation Tj initial = Tamb: 600 W; (2)P Power dissipation on infinite heatsink Tamb = 50℃: 5 W; (3)IFSM Non repetitive surge peak forward current for unidirectional types tp = 10ms Tj initial = Tamb: 100 A; (4)Tstg Storage temperature range: - 65 to + 175 ℃; Tj Maximum junction temperature: 150 ℃; (5)TL Maximum lead temperature for soldering during 10 s: 260 ℃.
Features
SM6T36CA features: (1)peak pulse power: 600 W (10/1000μs); (2)reakdown voltage range: from 6.8V to 220 V.; (3)uni and bidirectional types; (4)low clamping factor; (5)fast response time; (6)UL recognized.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SM6T36CA |
STMicroelectronics |
TVS Diodes - Transient Voltage Suppressors 600W 36V Bidirect |
Data Sheet |
|
|
||||||||||||
 |
SM6T36CA/1 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 600W 36V 5% Bidir |
Data Sheet |
Negotiable |
|
||||||||||||
|
SM6T36CA/2 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 600W 36V 5% Bi |
Data Sheet |
Negotiable |
|
||||||||||||
|
SM6T36CA/52 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 600W 36V 5% Bi |
Data Sheet |
Negotiable |
|
||||||||||||
|
SM6T36CA/55 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 600W 36V 5% Bi |
Data Sheet |
Negotiable |
|
||||||||||||
|
SM6T36CA/2B |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 600W 36V 5% Bidir |
Data Sheet |
Negotiable |
|
||||||||||||
|
SM6T36CA-E3/52 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 600W 36V 5% Bi |
Data Sheet |
|
|
||||||||||||
|
SM6T36CA-E3/5B |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 600W 36V 5% Bi |
Data Sheet |
|
|
||||||||||||
